TL;DR Export JStorm metrics and visualize with Grafana

JStorm Metrics System

JStorm’s UI provides a large number of very detailed monitoring parameters, which are extremely helpful for troubleshooting. For information about the UI, you can refer to my previous article: https://lichuanyang.top/posts/31996/. However, using the UI can sometimes be inconvenient, for example when you need to query historical data. Therefore, we want to export monitoring data to other storage media for easier subsequent querying and analysis.

Since JStorm’s monitoring has been completely rewritten compared to Apache Storm, the monitoring export methods found online for Storm are not applicable to JStorm. And apart from the official documentation, JStorm lacks resources. The official documentation is too brief, providing only some hints, and you need to combine these hints with source code to understand the details. So I’ve put together an example of exporting JStorm monitoring data.

Custom Metrics Upload

First, you need to implement the MetricUploader interface. However, we don’t actually use any of the methods in this interface. The main purpose is to use its TopologyMetricsRunnable parameter, and then use this parameter to retrieve monitoring information. So theoretically, as long as you obtain TopologyMetricsRunnable, you don’t necessarily have to implement the MetricUploader interface. My approach is to implement MetricUploader, and then start a scheduled thread pool to periodically fetch monitoring data.

JStorm’s metric data is stored in RocksDB. The data retrieved here is essentially querying RocksDB using JStorm’s wrapped interfaces.

Core Code Implementation

The specific code is as follows:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
ClusterSummary clusterInfo = client.getClient().getClusterInfo();
//get list of topologies in this cluster
List<TopologySummary> topologies = clusterInfo.get_topologies();
for (TopologySummary topology : topologies) {
    //get topology id and name
    //the id is used for query, name for human reading
    logger.info("topology info " + topology.get_id() + " " + topology.get_name());
    TopologyMetric metric = metricsRunnable.getTopologyMetric(topology.get_id());
    //get data of "component metrics" page in jstorm UI
    MetricInfo componentMetric = metric.get_componentMetric();
    Map<String, Map<Integer, MetricSnapshot>> metrics = componentMetric.get_metrics();
    for (Map.Entry<String, Map<Integer, MetricSnapshot>> oneMetric : metrics.entrySet()) {
        String[] key = oneMetric.getKey().split("@");
        String metricKey = key[1] + "@" + key[2] + "@" + key[6];
        //get(60) to get data in 1 min, also can get(600) for 10min, and so on
        logger.info("metric one minute data for " + metricKey + " " + oneMetric.getValue().get(60));
    }
}

Data Parsing and Output

The entire flow is quite clear. First, query the list of topologies in the cluster, then use each topology ID to query metric information, obtaining a TopologyMetric object. TopologyMetric contains topologyMetric, componentMetric, workerMetric, and other attributes, which correspond to the respective pages in the UI.

Taking componentMetric as an example, you can use componentMetric.get_metrics() to get the specific monitoring metric data. A metric is a Map<String, Map<Integer, MetricSnapshot>>, where the key is a string separated by ‘@’ characters, containing key information such as topology name, component name, and data item. The value of this map is a time (in seconds), corresponding to the 1-minute, 2-minute pages on the UI, and the value is the specific monitoring data. This data is actually richer than what the UI displays — besides averages, it also includes the 95th percentile, 99th percentile, etc.

In this example, I only output some of the data using logging. In practice, you can use storage media such as HBase, Redis, MySQL, etc. according to your needs.

The specific code can be viewed at https://github.com/lcy362/StormTrooper/blob/master/src/main/java/com/trooper/storm/monitor/MetricUploaderTest.java

Quick Start Guide

  1. Implement MetricUploader: Create a custom class implementing the MetricUploader interface. Use the TopologyMetricsRunnable object obtained via the constructor to query metrics from RocksDB.
  2. Write metrics collection logic: Call metricsRunnable.getTopologyMetric(topologyId) to get the TopologyMetric. Read componentMetric, workerMetric, and topologyMetric data, parse the @-delimited metric keys, and store them.
  3. Configure JStorm: Register your custom MetricUploader implementation in the JStorm config file to enable automatic metrics reporting at topology startup.
  4. Test: Start a topology and check whether metrics data is written to your target storage (HBase/Redis/MySQL, etc.). Cross-reference with the JStorm UI to ensure consistency.
  5. Connect Grafana: Configure the storage medium as a Grafana data source, write queries to build monitoring dashboards for historical data visualization and alerting.
