Hawtio (hawt.io) is an open-source monitoring system that provides multiple startup methods. It can run as a standalone JAR or WAR package and remotely connect to other applications for monitoring, or it can be directly embedded into our own applications.

This article introduces how to embed Hawtio in a standalone Java application, corresponding to the official documentation (http://hawt.io/getstarted/index.html) section “Using hawtio inside a stand alone Java application”. However, that section of the documentation has quite a few issues — if you only follow that section, you’ll encounter various problems.

Below are the detailed steps.

Adding Dependencies

In addition to the hawtio-embedded mentioned in the official documentation, the hawtio-insight-log, hawtio-core, and hawtio-web packages are all required. We use the latest versions available at the time.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
<dependency>
    <groupId>io.hawt</groupId>
    <artifactId>hawtio-embedded</artifactId>
    <version>2.0.0</version>
</dependency>
<dependency>
    <groupId>io.hawt</groupId>
    <artifactId>hawtio-insight-log</artifactId>
    <version>1.5.0</version>
</dependency>
<dependency>
    <groupId>io.hawt</groupId>
    <artifactId>hawtio-core</artifactId>
    <version>2.0.0</version>
</dependency>
<dependency>
    <groupId>io.hawt</groupId>
    <artifactId>hawtio-web</artifactId>
    <version>2.0.0</version>
</dependency>

Downloading the WAR Package

Also from the official getting started documentation (http://hawt.io/getstarted/index.html), download the hawtio-default.war package and place it anywhere. The WAR file name can be changed to anything you like.

Code

The basic code is very simple if no additional configuration is needed:

1
2
3
Main main = new Main();
main.setWar("hawtio.war");
main.run();

The main.setWar method configures the specific path to the WAR package. It can be inside or outside the project directory. Note that it is NOT “the directory path containing the Hawtio WAR” as stated in the official documentation.

Then run main.run() to start Hawtio.

Authentication

Newer versions of Hawtio require a password by default. For simplicity, you can add a JVM parameter to disable authentication:

1
-Dhawtio.authenticationEnabled=false

Example code can be found on GitHub (https://github.com/lcy362/CamelDemo/blob/master/src/main/java/com/mallow/demo/camel/MainWithHawtio.java). It can be downloaded and run directly, but you’ll need a local ActiveMQ instance. The example demonstrates using Hawtio to monitor Apache Camel. After startup, the Camel tab will appear directly in the Hawtio web interface, making it very convenient to use.
