ActiveMQ provides a plugin development mechanism (http://activemq.apache.org/developing-plugins.html) that allows you to conveniently add various custom functionalities. The effect is similar to directly modifying ActiveMQ’s source code, but using plugins is much better than modifying source code in terms of both convenience and risk. In theory, we can implement almost any functionality imaginable through this approach.

Development Guide

First, you need to add the ActiveMQ dependency to your project. For convenience, you can use the activemq-all package directly.

1
2
3
4
5
<dependency>
    <groupId>org.apache.activemq</groupId>
    <artifactId>activemq-all</artifactId>
    <version>5.13.2</version>
</dependency>

Developing an ActiveMQ plugin is very straightforward — you only need to implement two classes.

One is the plugin class, which needs to implement the BrokerPlugin interface, and then implement the installPlugin method.

The sole purpose of this method is to specify a broker class:

1
2
3
public Broker installPlugin(Broker broker) throws Exception {
    return new LimitQueueSIzeBroker(broker);
}

Next, you need to implement a broker class. In most cases, you can extend the BrokerFilter class, override the methods you need, and after the constructor and each overridden method finishes execution, call the corresponding method on the superclass. This way, it won’t affect ActiveMQ’s actual runtime.

For example:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
public FoxBroker(Broker next) {
    super(next);
}

@Override
public void send(ProducerBrokerExchange producerExchange, Message messageSend) throws Exception {
    try {
        String ip = producerExchange.getConnectionContext().getConnection().getRemoteAddress();
        String destinationName = messageSend.getDestination().getPhysicalName();
        logger.info("send_" + destinationName + " "  + ip);
    } catch (Exception e) {
        logger.error("activemq send log error: " + e, e);
    }
    super.send(producerExchange, messageSend);
}

Here we override ActiveMQ’s send method and add some logging.

Then package it and place the JAR file in ActiveMQ’s lib directory. Next, add the plugins module in activemq.xml and list the desired plugins inside:

1
2
3
4
<plugins>
	<bean xmlns="http://www.springframework.org/schema/beans" id="testPlugin" class="com.mallow.activemq.FoxBrokerPlugin"/>
	<bean xmlns="http://www.springframework.org/schema/beans" id="purgePlugin" class="com.mallow.activemq.LimitQueueSizePlugin"/>
</plugins>

Restart ActiveMQ, and you can see the effect when sending and receiving messages.

Examples

You can refer to the code I have on GitHub: https://github.com/lcy362/FoxActivemqPlugin

It provides two very simple plugin examples. FoxBrokerPlugin logs the IP addresses of producers and consumers when sending and receiving messages. LimitQueueSizePlugin can control the queue size — when the queue accumulates 1000 messages, new messages will be discarded, which is quite useful in test environments.

Additionally, ActiveMQ itself provides several commonly used plugins, including LoggingBrokerPlugin, StatisticsBrokerPlugin, etc., which you can also reference for implementation.
